| 20231.5T two-drive Tide Field version Plus |
20232.0T two-drive tide field version |
20232.0T two-drive Tide Field version Plus |
20232.0T four-wheel drive Tide field Plus |
| essential parameter |
| Energy type |
gasoline |
gasoline |
gasoline |
gasoline |
| Maximum power (kW) |
135 |
175 |
175 |
175 |
| Maximum torque (Nm) |
275 |
385 |
385 |
385 |
| engine |
1.5T 184 hp L4 |
2.0T 238 hp L4 |
2.0T 238 hp L4 |
2.0T 238 hp L4 |
| gear-box |
7 block wet type double clutch |
9 Stop wet double clutch |
9 Stop wet double clutch |
9 Stop wet double clutch |
| Long * width * height (mm) |
4705*1908*1780 |
4705*1908*1780 |
4705*1908*1780 |
4705*1908*1780 |
| bodywork |
A 5-door, 5-seat SUV |
A 5-door, 5-seat SUV |
A 5-door, 5-seat SUV |
A 5-door, 5-seat SUV |
| Top vehicle speed (km / h) |
180 |
200 |
200 |
200 |
| WLTC combined fuel consumption (L / 100km) |
7.64 |
7.95 |
7.95 |
8.58 |
| body of car |
| wheel base (mm) |
2810 |
2810 |
2810 |
2810 |
| front gauge (mm |
1641 |
1641 |
1641 |
1641 |
| rear track (mm |
1640 |
1640 |
1640 |
1640 |
| No-load minimum ground clearance (mm) |
200 |
200 |
200 |
200 |
| approach angle (°) |
24 |
24 |
24 |
24 |
| departure angle (°) |
30 |
30 |
30 |
30 |
| Number of seats (individual) |
5 |
5 |
5 |
5 |
| fuel tank capacity (L60 |
|
60 |
60 |
60 |
| Trunk volume (L |
483-1362 |
483-1362 |
483-1362 |
483-1362 |
| curb weight (kg |
1685 |
1740 |
1740 |
1840 |
| Maximum full load mass (kg |
2120 |
2170 |
2170 |
2275 |
| engine |
|
|
|
| engine type |
GW 4B15L |
GW4N20A |
GW 4N20A |
GW 4N2OA |
| displacement (mL) |
1499 |
1998 |
1998 |
1998 |
| Intake form |
turbocharging |
turbocharging |
turbocharging |
turbocharging |
| Maximum horsepower (Ps) |
184 |
238 |
238 |
238 |
| Maximum power (kW) |
135 |
175 |
175 |
175 |
| Maximum power rotation speed (rpm) |
5500-6000 |
6000 |
6000 |
6000 |
| Maximum torque (N · m) |
275 |
385 |
385 |
385 |
| Maximum torque rotation speed (rpm) |
1500-4000 |
1700-4000 |
1700-4000 |
1700-4000 |
| Maximum net power (kW) |
— |
170 |
170 |
170 |
| gear-box |
| Number of gear |
7 |
9 |
9 |
9 |
| Transmission type |
Wet dual-clutch transmission (DCT) |
Wet dual-clutch transmission (DCT) |
Wet dual-clutch transmission (DCT) |
Wet dual-clutch transmission (DCT) |
| the abbreviated form of a name |
7 block wet type double clutch |
9 Stop wet double clutch |
9 Stop wet double clutch |
9 Stop wet double clutch |
| Chassis steering |
|
|
| Drive way |
Front-engine |
Front-engine |
Front-engine |
Front-engine |
| Four-wheel drive form |
— |
— |
— |
Timely four-wheel drive |
| Central differential structure |
— |
— |
— |
Multiple clutch |
| Front suspension type |
McPherson type independent suspension |
McPherson type independent suspension |
McPherson type independent suspension |
McPherson type independent suspension |
| Rear suspension type |
Multi-link-type independent suspension |
Multi-link-type independent suspension |
Multi-link-type independent suspension |
Multi-link-type independent suspension |
| Power type |
Electric power |
Electric power |
Electric power |
Electric power |
| car body structure |
Carrying type |
Carrying type |
Carrying type |
Carrying type |
| Wheel brake |
| Front Brake Type |
Ventilation disc type |
Ventilation disc type |
Ventilation disc type |
Ventilation disc type |
| Rear brake type |
disk |
Ventilation disc type |
disk |
disk |
| Parking brake type |
Electronic parking |
Electronic parking |
Electronic parking |
Electronic parking |
| Front tire specifications |
235/60 R19 |
235/60 R19 |
235/60 R19 |
235/60 R19 |
| Rear tire specifications |
235/60 R19 |
235/60 R19 |
235/60 R19 |
235/60 R19 |
| Formal specification |
Non-full size |
Non-full size |
Non-full size |
Non-full size |
